اسمنت جديد Hartmann Silosy Monolityczne

2023
30-733 Kraków

معلومات رئيسية
مرجع الزبون:	WE36105
مرجع الموقع:	10086831
النوع	--
العلامة التجارية	Hartmann
الطراز	Silosy Monolityczne
الحالة	جديد
السنة	2023
البلد	بولونيا
صانع	Hartmann

أبعاد
حجم	4.615 متر مكعب

علبة التروس ونظام نقل الحركة
دقة علبة السرعات	Boîte automatique

ملاحظات

Localisation :
  • Pologne Krakówà
Citerne :
  • 4 mm
État :
  • vernis d''origine
  • peinture d''origine
Informations supplémentaires :
  • blanc

Cement silo 60 T
For bulk weight of cement 1m3= 1300kg

Steel superstructure on short bases

Silo to be founded on old legs.

Only short adapters will be supplied.

Silo drum welded - not bolted
Silo wall thickness 4mm
empty weight: approx. 4.5 tonnes

Silo with smooth shell (German version)
Silos with a capacity of:
30 to 100 T. (capacity in 10 T increments)

And 120, 150, 200 T.

Silo diameter from 2.22 to 3.08 M.

Certificates:

-TUV ISO 9001 certificate

-TUV ISO 1090 certificate

-TUV ISO 3834 certificate

Monolithic silos are completely welded, not bolted.
So there is no fear that they will start leaking after years!

Hartmann Cement Silo

ZementSilo ZS60.K

RAL colour white

Silo drum material: S355 steel

Max. loading capacity: 60 tonnes

Hartmann Cement Silo ZementSilo ZS60.K Colour RAL White Silo drum material: Steel S355
Steel connectors - Stubs for the transition from the silo drum to the old legs.
Filling line with Storz coupling
Replacement elbow on pipe with 2 quick-release couplings
Overfill safety valve
Pressure relief valve
Silo hatch

Price ex work Krakow net PLN 79,400.00 including items (1-7)

Recommended accessories for the silo:

WAM silo air filter with electric cable, without connection to node control
Aeration - cement aeration - 4 aeration nozzles
Electric valve for aeration control and electric and pneumatic lines
Silo pressure relief valve, without connection to control centre
Butterfly valve under the silo with handle, prepared for connection to the cement feeder
Cement screw feeder, with dust-free head, cable installation, without connection to control centre
Cables to fix the feeder, elastic sleeve, 2 bands. Preparation of inlet to the scales on the customer''s side
Cement level sensors in the silo: 1x MIN sensor and 1 x MAX sensor
Operating platform with railings and steps, ladder
Assembly (1 day)

مشاهدة الجميع

ملاحظات

سعر المبيعات

15,700 EUR دون احتساب الرسوم
