محملة بعجلات جديد Dragon Machinery ZL08F Small Loader

Articulated Mini Loader 800kg Capacity with heavy-duty bucket with bolt on teeth, enclosed cabin, adjustable suspension seat, digital radio & MP3 player, reversing camera, top beacon, and optional hydraulic joystick control and hydraulic quick coupler

Mini Wheel Loader ZL08F
Technical Specifications
1. Rated Load: 800kg
2. Operating Weight: 2850kg
3. Rated Bucket Capacity: 0.4CBM
4. Bucket Width: 1300mm
5. Max. Breakout Force: 28KN
6. Max. Tilt Angle of Cabin: 30deg.
7. Max. Dumping Height: 2300mm
8. Max. Dumping Reach: 750mm
9. Raising Time: < 4.0s
10. Hydraulic Cycle Time: 9s
11. Min. Ground Clearance: 240mm
12. Overall Dimensions (L x W x H): 4100x1600x2450mm
13. Min. Turning Radius: 4600mm
14. Engine Model: CHANGCHAI ZN390Q
15. Engine Type: Horizontal, Water-cooled Evaporative, Three-cylinder Diesel Engine
16. Rated Engine Power: 25kW
17. Rated Engine Speed: 2400rpm
18. Transmission Mode: Automatic Transmission (with torque converter)
19. Gear Shift: 3 Forward, 1 Reverse
20. Max. Speed: 25km/h
21. Mode of Axle: 130 Drive Axle
22. Wheel Tread: 1285mm
23. Wheel Base: 2170mm
24. Drive Mode: 4-wheel Drive
25. Full Hydraulic Steering System: BZZ-80
26. System Working Pressure: 10 Mpa
27. Service Brake: Foot Pedal Hydraulic Expansion-shoe Brake on 4 Wheels
28. Parking Brake: Hand Lever Flexible Shaft Controlled Disc Brake
29. Tyre Type Specification: 8.25-16-14PR (Width: 200mm, Dia.: 800mm)
30. Front Tyre Pressure: 0.40Mpa
31. Rear Tyre Pressure: 0.35Mpa

Note:
1. All photos are for reference only.
2. Machines shown may include optional parts.
3. All specifications and design characteristics are subject to change without prior notice
